| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Package / Case | Capacitance @ Vr, F | Supplier Device Package | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature - Junction | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HERAF1604GDIODE GEN PURP 16A 300V IT0-220A |
12,699 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 150pF @ 4V, 1MHz | 50 ns | 10 µA @ 300 V | 300 V | 16A (DC) | -55°C ~ 150°C | 1 V @ 16 A | ||||
|
|
MBR1660DIODE SCHOTTKY 60V 16A TO220 |
12,955 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 60 V | 60 V | 16A (DC) | -55°C ~ 150°C | 750 mV @ 16 A | ||||
|
|
UGF10JDIODE GEN PURP 600V 10A ITO220AC |
11,853 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 25 ns | 5 µA @ 600 V | 600 V | 10A (DC) | -55°C ~ 150°C | 2 V @ 10 A | ||||
|
SR1503HDIODE SCHOTTKY 15A 30V R-6 |
13,624 | 0.00 |
FFQ |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 30 V | 30 V | 15A (DC) | -55°C ~ 150°C | 550 mV @ 15 A | |||
|
SF32GDIODE GEN PURP 100V 3A DO201AD |
12,189 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 80pF @ 4V, 1MHz | 35 ns | 5 µA @ 100 V | 100 V | 3A (DC) | -55°C ~ 150°C | 950 mV @ 3 A | ||||
|
|
SF63GHDIODE GEN PURP 6A 150V DO-201AD |
13,975 | 0.00 |
FFQ |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 100pF @ 4V, 1MHz | 35 ns | 5 µA @ 150 V | 150 V | 6A (DC) | -55°C ~ 150°C | 975 mV @ 6 A | |||
|
|
SF63GDIODE GEN PURP 6A 150V DO-201AD |
10,837 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 100pF @ 4V, 1MHz | 35 ns | 5 µA @ 150 V | 150 V | 6A (DC) | -55°C ~ 150°C | 975 mV @ 6 A | ||||
|
HER201GDIODE GEN PURP 2A 50V DO-15 |
10,136 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 35pF @ 4V, 1MHz | 50 ns | 5 µA @ 50 V | 50 V | 2A (DC) | -55°C ~ 150°C | 1 V @ 2 A | ||||
|
|
SFAF1608GDIODE GEN PURP 600V 16A ITO220AC |
10,051 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 100pF @ 4V, 1MHz | 35 ns | 10 µA @ 600 V | 600 V | 16A (DC) | -55°C ~ 150°C | 1.7 V @ 16 A | ||||
|
|
FR151GDIODE FAST REC 1.5A 50V DO-15 |
14,747 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 20pF @ 4V, 1MHz | 150 ns | 5 µA @ 50 V | 50 V | 1.5A (DC) | -55°C ~ 150°C | 1.3 V @ 1.5 A | ||||
|
|
SR509DIODE SCHOTTKY 5A 90V DO-201AD |
14,749 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 100 µA @ 90 V | 90 V | 5A (DC) | -55°C ~ 150°C | 850 mV @ 5 A | ||||
|
|
SRAF1040DIODE SCHOTTKY 40V 10A ITO220AC |
12,501 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 40 V | 40 V | 10A (DC) | -55°C ~ 125°C | 550 mV @ 10 A | ||||
|
|
UGA15120DIODE GEN PURP 15A TO220AC |
14,786 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 65 ns | 5 µA @ 1200 V | 1200 V | 15A (DC) | -55°C ~ 175°C | 2.9 V @ 15 A | ||||
|
|
UF5JFCDIODE GEN PURP 600V 5A ITO220AC |
13,439 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 30pF @ 4V, 1MHz | 25 ns | 30 µA @ 600 V | 600 V | 5A (DC) | -55°C ~ 150°C | 2.8 V @ 5 A | ||||
|
|
1N4933GHDIODE GEN PURP 50V 1A DO41 |
12,259 | 0.00 |
FFQ |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 10pF @ 4V, 1MHz | 200 ns | 5 µA @ 50 V | 50 V | 1A (DC) | -55°C ~ 150°C | 1.2 V @ 1 A | |||
|
|
UGA8120HDIODE GEN PURP 8A TO220AC |
11,971 | 0.00 |
FFQ |
Tube | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 70 ns | 5 µA @ 1200 V | 1200 V | 8A (DC) | -55°C ~ 175°C | 2.8 V @ 8 A | |||
|
|
1N4934GDIODE GEN PURP 100V 1A DO41 |
12,121 | 0.00 |
FFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 10pF @ 4V, 1MHz | 200 ns | 5 µA @ 100 V | 100 V | 1A (DC) | -55°C ~ 150°C | 1.2 V @ 1 A | ||||
|
|
GPA804DIODE GEN PURP 8A 400V TO220AC |
12,570 | 0.00 |
FFQ |
Tube | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | 50pF @ 4V, 1MHz | - | 5 µA @ 400 V | 400 V | 8A (DC) | -55°C ~ 150°C | 1.1 V @ 8 A | ||||
|
|
SF33GHDIODE GEN PURP 150V 3A DO201AD |
14,735 | 0.00 |
FFQ |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 80pF @ 4V, 1MHz | 35 ns | 5 µA @ 150 V | 150 V | 3A (DC) | -55°C ~ 150°C | 950 mV @ 3 A | |||
|
|
MBRF760DIODE SCHOTTKY 60V 7.5A ITO220AC |
11,843 | 0.00 |
FFQ |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 100 µA @ 60 V | 60 V | 7.5A (DC) | -55°C ~ 150°C | 750 mV @ 7.5 A |
