Results:

Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	DiodeType	Voltage-PeakReverse(Max)	Current-Max	Capacitance@VrF	Resistance@IfF	PowerDissipation(Max)	OperatingTemperature
BAT2402LSE6327XTSA1 DIODE SCHOTTKY 4V 100MW TSSLP-2 Infineon Technologies	7,212	1.41	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Schottky - Single	4V	110 mA	0.23pF @ 0V, 1MHz	-	100 mW	150°C (TJ)
BAR63-02LE6327 PIN DIODE, 50V V(BR) Infineon Technologies	14,345	0.05	- + FFQ	Datasheet	Bulk	-	Active	PIN - Single	50V	100 mA	0.3pF @ 5V, 1MHz	-	250 mW	150°C (TJ)
BAR6304WH6327 RF PIN DIODE > ANTENNA SWITCH Infineon Technologies	10,332	0.06	- + FFQ	Datasheet	Bulk	-	Active	PIN - 1 Pair Series Connection	50V	100 mA	0.3pF @ 5V, 1MHz	-	250 mW	150°C (TJ)
BAR6406WE6327 RF PIN DIODE > ANTENNA SWITCH Infineon Technologies	13,624	0.07	- + FFQ	Datasheet	Bulk	-	Active	PIN - Single	150V	100 mA	0.35pF @ 20V, 1MHz	1.35Ohm @ 100mA, 100MHz	250 mW	150°C (TJ)
BAT17-06WE6327 RF MIXER/DETECTOR SCHOTTKY DIODE Infineon Technologies	12,125	0.07	- + FFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-
BAT17-06WH6327 RF MIXER/DETECTOR SCHOTTKY DIODE Infineon Technologies	14,754	0.07	- + FFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-
BAT-17-07 MIXER DIODE, VHF TO UHF Infineon Technologies	12,397	0.13	- + FFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-
BAR81WE6327 PIN DIODE Infineon Technologies	12,724	0.15	- + FFQ	Datasheet	Bulk	-	Active	Standard - Single	30V	100 mA	0.9pF @ 3V, 1MHz	1Ohm @ 5mA, 100MHz	100 mW	150°C (TJ)
BAT1805E6327HTSA1 PIN DIODE, 35V V(BR) Infineon Technologies	11,427	0.16	- + FFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-
BAT15-05WH6327XTSA1 RF MIXER/DETECTOR SCHOTTKY DIODE Infineon Technologies	13,963	0.19	- + FFQ	Datasheet	Bulk	-	Active	Schottky - 1 Pair Common Cathode	4V	110 mA	0.5pF @ 0V, 1MHz	5.5Ohm @ 50mA, 1MHz	100 mW	150°C (TJ)
BAT15-05WH6327XTSA3 RF MIXER/DETECTOR SCHOTTKY DIODE Infineon Technologies	10,534	0.19	- + FFQ	Datasheet	Bulk	-	Active	Schottky - 1 Pair Common Cathode	4V	110 mA	0.5pF @ 0V, 1MHz	5.5Ohm @ 50mA, 1MHz	100 mW	150°C (TJ)
BAT15-05WH6327XTSA2 RF MIXER/DETECTOR SCHOTTKY DIODE Infineon Technologies	10,783	0.19	- + FFQ	Datasheet	Bulk	-	Active	Schottky - 1 Pair Common Cathode	4V	110 mA	0.5pF @ 0V, 1MHz	5.5Ohm @ 50mA, 1MHz	100 mW	150°C (TJ)
BAT15-098LRH MIXER DIODE, LOW BARRIER, X BAND Infineon Technologies	12,314	0.19	- + FFQ	Datasheet	Bulk	-	Active	Schottky - 2 Pair Common Cathode	4V	110 mA	0.5pF @ 0V, 1MHz	-	100 mW	150°C (TJ)
BAR64-03W BAR64 - PIN DIODE Infineon Technologies	12,087	0.07	- + FFQ	Datasheet	Bulk	-	Active	-	-	-	-	-	-	-
BAR64-03WE6327 BAR64 - PIN DIODE Infineon Technologies	10,490	0.07	- + FFQ	Datasheet	Bulk	-	Active	PIN - Single	150V	100 mA	0.35pF @ 20V, 1MHz	1.35Ohm @ 100mA, 100MHz	250 mW	150°C (TJ)
BAT1706WH6327XTSA1 DIODE SCHOTTKY 4V 150MW SOT323-3 Infineon Technologies	818	0.37	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Obsolete	Schottky - 1 Pair Common Anode	4V	130 mA	0.75pF @ 0V, 1MHz	15Ohm @ 5mA, 10kHz	150 mW	150°C (TJ)
BAT1704E6327HTSA1 DIODE SCHOTTKY 4V 150MW SOT23-3 Infineon Technologies	14,493	0.51	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Schottky - 1 Pair Series Connection	4V	130 mA	0.75pF @ 0V, 1MHz	15Ohm @ 5mA, 10kHz	150 mW	150°C (TJ)
BAR6305E6327HTSA1 RF DIODE PIN 50V 250MW SOT23-3 Infineon Technologies	13,889	0.52	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	PIN - 1 Pair Common Cathode	50V	100 mA	0.3pF @ 5V, 1MHz	1Ohm @ 10mA, 100MHz	250 mW	150°C (TJ)
BAT62E6327HTSA1 DIODE SCHOTTKY 40V 100MW SOT143 Infineon Technologies	10,964	0.55	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	Schottky - 2 Independent	40V	20 mA	0.6pF @ 0V, 1MHz	-	100 mW	150°C (TJ)
BAR6302VH6327XTSA1 RF DIODE PIN 50V 250MW SC79-2 Infineon Technologies	14,862	0.38	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	-	Active	PIN - Single	50V	100 mA	0.3pF @ 5V, 1MHz	1Ohm @ 10mA, 100MHz	250 mW	150°C (TJ)
