Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
SN74S10NSRG4 IC GATE NAND 3CH 3-INP 14SOP Texas Instruments	2,523	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	NAND Gate	3	3	-	4.75V ~ 5.25V	-	1mA, 20mA	0.8V	2V	5ns @ 5V, 50pF	0°C ~ 70°C	Surface Mount
SN74S132DG4 IC GATE NAND 4CH 2-INP 14SOIC Texas Instruments	2,863	0.00	- + FFQ	Datasheet	Tube	74S	Obsolete	NAND Gate	4	2	Schmitt Trigger	4.75V ~ 5.25V	-	1mA, 20mA	1.1V	1.9V	13ns @ 5V, 15pF	0°C ~ 70°C	Surface Mount
SN74S132DRG4 IC GATE NAND 4CH 2-INP 14SOIC Texas Instruments	2,748	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	NAND Gate	4	2	Schmitt Trigger	4.75V ~ 5.25V	-	1mA, 20mA	1.1V	1.9V	13ns @ 5V, 15pF	0°C ~ 70°C	Surface Mount
SN74S32NSRG4 IC GATE OR 4CH 2-INP 14SOP Texas Instruments	3,152	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	OR Gate	4	2	-	4.75V ~ 5.25V	-	1mA, 20mA	0.8V	2V	5ns @ 5V, 50pF	0°C ~ 70°C	Surface Mount
SN74S37DRG4 IC GATE NAND 4CH 2-INP 14SOIC Texas Instruments	3,515	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	NAND Gate	4	2	-	4.75V ~ 5.25V	-	3mA, 60mA	0.8V	2V	6ns @ 5V, 150pF	0°C ~ 70°C	Surface Mount
SN74S37NSRG4 IC GATE NAND 4CH 2-INP 14SOP Texas Instruments	2,117	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	NAND Gate	4	2	-	4.75V ~ 5.25V	-	3mA, 60mA	0.8V	2V	6ns @ 5V, 150pF	0°C ~ 70°C	Surface Mount
SN74S86DRG4 IC GATE XOR 4CH 2-INP 14SOIC Texas Instruments	2,042	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	XOR (Exclusive OR)	4	2	-	4.75V ~ 5.25V	-	1mA, 20mA	0.8V	2V	10.5ns @ 5V, 15pF	0°C ~ 70°C	Surface Mount
SN74S86NSRG4 IC GATE XOR 4CH 2-INP 14SOP Texas Instruments	3,858	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74S	Obsolete	XOR (Exclusive OR)	4	2	-	4.75V ~ 5.25V	-	1mA, 20mA	0.8V	2V	10.5ns @ 5V, 15pF	0°C ~ 70°C	Surface Mount
SN74LVC3G14DCU6 IC INVERT SCHMITT 3CH 3IN 8VSSOP Texas Instruments	3,165	0.00	- + FFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Obsolete	Inverter	3	3	Schmitt Trigger	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.3V ~ 1.4V	1.4V ~ 3.7V	4.3ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
1P1G08MDBVREPG4 IC GATE AND 1CH 2-INP SOT23-5 Texas Instruments	14,151	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	-	Discontinued at Mosen	AND Gate	1	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	5ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
5962-8754903VDA IC GATE NAND 4CH 2-INP 14CFP Texas Instruments	689	433.65	- + FFQ	Datasheet	Bulk	-	Active	NAND Gate	4	2	-	2V ~ 6V	4 µA	24mA, 24mA	0.1V ~ 0.36V	2.56V ~ 4.86V	8ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
5962-8761203VDA IC GATE NOR 4CH 2-INP 14CFP Texas Instruments	889	362.69	- + FFQ	Datasheet	Bulk	-	Active	NOR Gate	4	2	-	1.5V ~ 5.5V	4 µA	24mA, 24mA	0.3V ~ 1.65V	1.2V ~ 3.85V	11.5ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
74LVC2G132DCTRG4 IC GATE NAND SCHMITT 2CH 2IN SM8 Texas Instruments	14,910	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Discontinued at Mosen	NAND Gate	2	2	Schmitt Trigger	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.39V ~ 1.87V	1.16V ~ 3.33V	6ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
SN74LV14AMPWREPG4 IC INVERTER 6CH 1-INP 14TSSOP Texas Instruments	12,095	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LV	Discontinued at Mosen	Inverter	6	1	Schmitt Trigger	2V ~ 5.5V	20 µA	12mA, 12mA	0.75V ~ 1.5V	1.75V ~ 3.5V	10.6ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
SN74LVC08AMPWREPG4 IC GATE AND 4CH 2-INP 14TSSOP Texas Instruments	10,745	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Discontinued at Mosen	AND Gate	4	2	-	2V ~ 3.6V	10 µA	24mA, 24mA	0.8V	2V	4.1ns @ 3.3V, 50pF	-55°C ~ 125°C	Surface Mount
SN74LVC2G32DCTRG4 IC GATE OR 2CH 2-INP SM8 Texas Instruments	12,444	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Discontinued at Mosen	OR Gate	2	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	3.2ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
SN74LVC32AMPWREPG4 IC GATE OR 4CH 2-INP 14TSSOP Texas Instruments	14,982	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Discontinued at Mosen	OR Gate	4	2	-	2V ~ 3.6V	10 µA	24mA, 24mA	0.8V	2V	3.8ns @ 3.3V, 50pF	-55°C ~ 125°C	Surface Mount
1P1G14MDBVREPG4 IC INVERTER 1CH 1-INP SOT23-5 Texas Instruments	14,893	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Discontinued at Mosen	Inverter	1	1	Schmitt Trigger	1.65V ~ 5.5V	19 µA	32mA, 32mA	0.39V ~ 1.87V	1.16V ~ 3.33V	5ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
CLVC1G32MDCKREPG4 IC GATE OR 1CH 2-INP SC70-5 Texas Instruments	3,471	0.00	- + FFQ	Datasheet	Tape & Reel (TR)	74LVC	Obsolete	OR Gate	1	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	4.5ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
SN74HC04ANSRE4 IC INVERTER 6CH 1-INP 14SOP Texas Instruments	2,995	0.00	- + FFQ		Tape & Reel (TR)	74HC	Obsolete	Inverter	6	1	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	13ns @ 6V, 50pF	-40°C ~ 85°C	Surface Mount
